Kodiak | 14" Overlapping 6 Head Concrete Grinder
GCONF14
Rental Item Details
| Head Size | 14" |
| Head Style | 6 overlapping heads |
| Diamond Inserts | 2 inserts per head, 12 total |
| Diamond Insert style | Magna-Trap |
| Grinding distance from wall | 1/8" (no edging required!) |
| Electronically Governed VFD motor | 15A, 120V |
| Polishing | 400-650 sq ft/hour |
| Grinding & Surface prep | 300-450 sq ft/hour |
The Kodiak Pro Grinding system is a configuration of 6 over-lapping counter rotating heads that provide an aggressive full coverage grind that gets within an 1/8" of a wall eliminating the need for time consuming edging.
The 1.5HP VFD controlled motor runs on a 120V 15A circuit and will keep the motor draw voltage within this range to prevent blowing breakers.
The 6 counter rotating heads with two magna trap accessories per head provide a consistent grind from prep at 16 grit to polish at 3000 grit. This configuration provides greater performance than similar 20" planetary grinders.
