Hammer Drill, SDS MAX, Rotary Hammer

Delivery from $18.00 · if machine is available

Delivery + pickup included. Equipment, capacity and timing confirmed at booking.

Delivery rules & ratesNeed it sooner? Give us a call

Hammer Drill, SDS MAX, Rotary Hammer

ELEDSDS

Rental Item Details

Heavy Hammer Drill SDS Max 120 volt	Model D25773K DeWalt
Weight	23.2 lbs
DELIVERY ESTIMATE	GET RATE

Manuals

Owners Manual, Makita HR4013C

Spec Sheet, Makita HR4013C

User Manual, Bosch RH1255VC, Rotary Hammer Drill

Parts List, Bosch RH1255VC, Rotary Hammer Drill

User Manual, Dewalt D25773K

User Manual, Bosch 11264EVS

Powerful 2" Hammer Drills from Dewalt, Bosch and Makita Gap Power stocks a full range of rental bits, core bits, and chisels

Equipped with the latest in anti vibration and anti rotation technology like the DEWALT anti-rotation E-Clutch® system or the Makita AVT. Sometimes referred to as a cement drill, hammer drill or concrete drill.

Also known as jack hammer or concrete breaker or power chisel or electric chisel or handheld concrete chipper.

FAQ

When is an SDS Max rotary hammer the right choice over an SDS Plus drill or a jackhammer?

This tool is commonly used for: drilling heavy concrete anchor holes; coring plumbing and electrical penetrations through foundation walls; light trenching and floor chipping; peeling tile or mortar beds; and chipping out masonry openings. Choose this 23 lb rotary hammer when you need both high-impact drilling up to 2 inches and chisel chipping in a single tool. For anchors under 5/8-inch, rent a lighter SDS Plus drill to reduce fatigue; for breaking slabs thicker than 4 inches, use a dedicated 60-lb electric breaker.

What style of bits and chisels work with this hammer drill?

This machine takes SDS Max shank tooling only; standard smooth shanks and smaller SDS Plus bits will not fit or lock into the chuck. Gap Power stocks a full selection of SDS Max carbide drill bits, core bits, bull points, flat chisels, and scaling chisels available for rent alongside the tool. Be sure to select the bit diameter and length that matches your required depth and hole diameter. Hammer Drill rental includes a popint, 1", 2", and 3" inch chisels.

Can this tool be used for chipping without the bit rotating?

Yes, this combination rotary hammer features selectable modes for rotary hammer drilling and hammer-only chipping. In chipping mode, rotation is locked so you can operate bull point and flat chisels like a mini handheld jackhammer. Always stop the motor completely before switching modes to ensure internal gears engage properly.

What electrical power and extension cord does this rotary hammer require?

This 120-volt tool draws heavy current under load and should be plugged into a standard, grounded 15-amp or 20-amp circuit without other high-draw appliances running. If you must use an extension cord, use a minimum 12-gauge cord up to 50 feet or a 10-gauge cord up to 100 feet. Undersized cords cause voltage drop that can trip breakers, reduce impact power, and overheat the motor.

How does the anti-rotation clutch protect the operator if a bit binds?

When drilling into reinforced concrete, bits can instantly snag on embedded steel rebar or dense aggregate. The machine features an integrated anti-rotation clutch system that cuts motor drive when a sudden bind is detected, preventing the tool from twisting violently out of your hands. Even with this protection, always maintain a firm, balanced two-handed grip and position the adjustable side handle securely before drilling.

What is the maximum drilling capacity for this hammer?

This heavy-duty unit is rated for solid carbide hammer drilling up to 2 inches in diameter and accommodates even larger core bits for wall penetrations. While it can drill smaller holes, its 23.2-lb operating weight and heavy impact energy make it best suited for medium-to-large diameter drilling from 5/8 inch to 2 inches.
