Tips and electrodes are included with your rental. Cut mild steel and aluminum with this 120 or 240 volt plasma cutter rental. The more voltage the thicker and faster you can cut. Adapters for various electric receptacles are also included. This plasma cutter requires a minimum of a 6 CFM @ 90 PSI air compressor.

Click here for more information on the features of this plasma cutter rental.

Mild Steel Recommended Cut Speeds at 40 Amps

Thickness/ Approximate Travel Speeds*

1/8 in. (3.2 mm) 156 IPM (3963 mm/min)

1/4 in. (6.4 mm) 64 IPM (1626 mm/min)

3/8 in. (9.5 mm) 36 IPM (915 mm/min)

1/2 in. (12.7 mm) 22 IPM (559 mm/min)

5/8 in. (15.9 mm) 13 IPM (330 mm/min)

Mild Steel Recommended Cut Speeds at 27 Amps

Thickness/ Approximate Travel Speeds*

12 ga. (2.8 mm) 115 IPM (2921 mm/min)

1/8 in. (3.2 mm) 88 IPM (2235 mm/min)

3/16 in. (4.8 mm) 50 IPM (1280 mm/min)

1/4 in. (6.4 mm) 28 IPM (711 mm/min)

3/8 in. (9.5 mm) 15 IPM (386 mm/min)

1/2 in. (12.7 mm) 8 IPM (203 mm/min)

5/8 in. (15.9 mm) 5 IPM (126 mm/min)

*Travel speeds are approximately 80% of maximum.
