Overview
The Prosource Pipe Bushing (35-3/8X1/4B) is designed for plumbing and piping systems requiring a reducing connection between 3/8 in and 1/4 in threaded fittings. This hex bushing provides a reliable MIP x FIP threaded transition in black malleable iron construction, rated for demanding pressure and temperature conditions.
| Specification | Value |
|---|---|
| MPN | 35-3/8X1/4B |
| Brand | Prosource / Worldwide Sourcing |
| Nominal Size | 3/8 x 1/4 in |
| Connection Type | MIP x FIP (Male Iron Pipe x Female Iron Pipe) |
| Pressure Rating | 300 PSI |
| Operating Temperature | -4 to 572°F |
| Schedule Rating | SCH 40 |
| Hex Size | 0.68 in |
| Length | 0.64 in |
| Material | Malleable Iron |
| Finish / Color | Black |
| Weight | 3.91 lb |
Technical Features
- 300 PSI pressure rating: Supports high-pressure pipe systems, reducing the need for supplemental pressure management at the fitting joint.
- Wide operating temperature range (-4 to 572°F): Suitable for both cold-water and high-temperature steam or hot-fluid applications without fitting degradation.
- Malleable iron construction: Provides superior impact resistance and ductility compared to cast iron, allowing the fitting to withstand mechanical stress without fracturing.
- SCH 40 schedule rating: Confirms wall thickness compatibility with standard Schedule 40 pipe assemblies for consistent, leak-free joints.
- MIP x FIP threaded connection: Enables direct inline installation as a reducing bushing, threading the male end into a larger female fitting to step down from 3/8 in to 1/4 in.
- 0.68 in hex size: Accommodates standard wrenching with common hand tools for precise torque application during installation.
- Black finish: Consistent with black iron pipe systems commonly used in gas, air, and industrial fluid distribution.
Applications
- Reducing pipe connections from 3/8 in to 1/4 in in threaded iron pipe systems
- Natural gas and propane distribution lines utilizing black iron pipe
- Compressed air systems requiring SCH 40-rated fittings
- Industrial fluid transfer systems operating within the rated pressure and temperature parameters
- Steam piping applications within the -4 to 572°F operating range
